Chapter 12 Installing, Removing, and Replacing

Adding, Removing, and Replacing the FC I/O Fan Blade

Scalar i500 User’s Guide 461

Figure Figure 62 on page 451 shows the FC I/O blade and I/O fan blade

installed side-by-side in the expansion module.

Adding an FC I/O Fan

Blade 12

These instructions explain how to add an FC I/O fan blade to your

library. You can add an FC I/O fan blade while the library is powered on.

Required tools: None

1 Access the back of the expansion module.

2 Remove the cover plate from blade bay to the right of the bay for the

FC I/O blade.

3 Press up and out to open the latch hooks on each side of the FC I/O

fan blade. The LED must be at the bottom of the blade.

Note: The recommended order of installing the FC I/O blade

and fan blade in an expansion module is starting from the

bottom two bays and moving up.
