Chapter 1 Description
Back Panel Components
Scalar i500 User’s Guide 26
Figure 8 Library Control Blade
Fibre-Channel
Input/Output Blades 1
Expansion modules support optional Fibre Channel (FC) Input/Output
(I/O) blades that provide connections for FC tape drives in the library.
Each FC I/O blade has an embedded controller that provides
connectivity and features that enhance the performance and reliability of
1 LEDs (blue, amber, green)
2 Gigabit Ethernet (external network) port
3 Ethernet I/O blade control ports (inactive if FC
I/O blades are not installed)
4 Service Ethernet port
5 Service serial port
