Chapter 3 Configuring Your Library
Configuring I/E Station Slots
Scalar i500 User’s Guide 81
Table 4 Number of I/E Station
Slots Available
Details on configuring I/E station slots include:
• Before changing the number of I/E station slots, remove all tape
cartridges from any slots currently configured as I/E station slots.
• An I/E station that has been configured for storage may contain
cleaning slots. These cleaning slots must be deleted before you can
reconfigure the storage slots as I/E station slots.
• The default number of dedicated I/E slots is six. If you accept the
Setup Wizard default configuration settings, six I/E slots will be
created in the control module.
• If you increase the size of your library by adding expansion modules,
the I/E stations in the new modules will be storage slots by default.
You can select to reconfigure these slots as I/E slots.
• Based on the number of I/E slots you configure, the library
automatically determines which I/E stations to configure as I/E slots
and which to configure as storage.
• The library configures I/E slots in the control module I/E station first
and then works outward to the I/E stations in the expansion
modules. I/E stations in expansion modules below the control
module have precedence over I/E stations in expansion modules
above the control module.
Library
Configuration 5U Control Module 9U Expansion Module Library Total
I/E
Stations
I/E
Slots
I/E
Stations
I/E
Slots
I/E
Stations
I/E
Slots
5U 16–– 1 6
14U 1 6 1 12 2 18
23U 1 6 2 24 3 30
32U 1 6 3 36 4 42
41U 1 6 4 48 5 54
