Chapter 12 Installing, Removing, and Replacing
Cabling the Library
Scalar i500 User’s Guide 298
Figure 40 Stand-Alone 5U
Control Module SCSI Cabling
1 Ethernet cable to customer
network
2 GB Ethernet port
3 SCSI terminator
4 Power supply
5 Rear power switch
6 SCSI cable to host
7 Library control blade
8 Module terminators
