Quantum Scalar i500

Chapter 12 Installing, Removing, and Replacing
Tape Drive Ethernet Connectivity and the Ethernet Expansion Blade
Scalar i500 User’s Guide 482
Figure 69 Ethernet Expansion
Blade LEDs
Ethernet Expansion blade
status LEDs
- Left = Blue
- Middle = Amber
- Right = Green
Port LED status
