Chapter 12 Installing, Removing, and Replacing
Cabling the Library
Scalar i500 User’s Guide 309
Figure 46 Multi-Module Fibre
Channel Cabling
1 Ethernet cable to network
2 GB Ethernet port
3 Power supply
4 Rear power switch
5 Power cords
6 Fibre cables to host
7 Module terminators
8 Library control blade (LCB)
9 Module-to-module cable
