Quantum Scalar i500

Chapter 1 Description
Front Panel Components
Scalar i500 User’s Guide 18
Front Panel Components
Figure 5 shows the front panel components of the library. The paragraphs
following Figure 5
describe the components in detail.
Figure 5 Front Panel
Components
1 Access door
2 Operator panel
3 I/E station
4 Front power button
