Chapter 12 Installing, Removing, and Replacing
Cabling the Library
Scalar i500 User’s Guide 296
Figure 38 HP LTO-5 Single
Port SAS Tape Drive
Figure 39 IBM LTO-5 Single
Port Fibre Channel Tape Drive
1 Ethernet port - do not use
2 SAS port - use this port
1 Ethernet port - do not use
2 Fibre Channel port - use this port
