Chapter 13 Troubleshooting
Interpreting LEDs
Scalar i500 User’s Guide 511
Servicing the LCB Based
on LED Status 13
1 Observe the blinking patterns of the LEDs for at least 30 seconds.
2 Capture a snapshot of the library, and send it to Quantum Technical
Support for analysis.
Tape Drive LEDs 13
RAS tickets typically report all problems related to tape drives, including
error codes and TapeAlerts. By observing the blinking pattern of LEDs on
tape drives, however, you can discern which operation the tape drive is
currently performing.
Figure 71
shows where the tape drive LEDs and the fibre port link LED
are located.
Figure 71 Location of Tape
Drive LEDs
Use Table 16 to interpret tape drive activity:
1 Fibre Port LED
2 Tape Drive LEDs
