Chapter 12 Installing, Removing, and Replacing
Cabling the Library
Scalar i500 User’s Guide 304
Figure 43 Stand-Alone Control
Module SAS Cabling
1 Ethernet cable to network
2 GB Ethernet port
3 Power supply
4 Rear power switch
5 Power cord
6 SAS cable to host
7 Library control blade
8 Module terminators
