Chapter 12 Installing, Removing, and Replacing
Removing and Replacing the Library Control Blade and LCB Compact Flash Card
Scalar i500 User’s Guide 408
Removing and Replacing the Library Control Blade and
LCB Compact Flash Card
The library control blade (LCB) manages the entire library, including the
operator panel and robot, and is responsible for running system tests to
ensure that the library is functioning properly.
The LCB compact flash card contains important information about your
library configuration. If you replace the compact flash card, then you
need to reconfigure your library. You have two options:
• Replacing the LCB/Compact Flash Card or Compact Flash Card
Only
• Replacing the LCB Only
Contact Quantum Support to determine which component(s) you need to
replace and which set of instructions to follow.
Replacing the
LCB/Compact Flash Card
or Compact Flash Card
Only 12
Contact Quantum Support to help you determine whether to replace the
LCB and compact flash card together, or to replace just the compact flash
card. The instructions for both options are nearly identical, except that for
a compact flash card-only replacement, you will reuse the existing LCB
and replace only the compact flash card within it. You will still need to
upgrade firmware as described below.
Equipment Required 12
• Ethernet Cable.
• Host PC or laptop connected to the Scalar i500 library.
• Current Scalar i500 library firmware file saved to your host PC or
laptop. Contact Quantum Support for the firmware, if needed.Latest
library configuration saved on PC or laptop.
