Quantum Scalar i500

Chapter 12 Installing, Removing, and Replacing
Installing the Library in a Rack
Scalar i500 User’s Guide 427
Table 10 Rack Ear Kit
Contents
Component Description
Quantity
Required
Nut clip — Used in
racks with square holes
4
Cage nut — Used in
racks with round holes
4
M5 thumbscrew —
Secures the rack ears
4
Rack ear, left — Holds
the modules in the rack
1
