Chapter 12 Installing, Removing, and Replacing

Installing a New Multi-Module Library Configuration

Scalar i500 User’s Guide 339

a From the front of the library, open the I/E station and access

doors of the expansion module. Squeeze the handle of the Y-rail

release mechanism, lift it out of its locked position, and slide it

downward as far as it will go.

b From the back of the library, find the rear Y-rail release

mechanism, which is located in the interior of the right side of the

module. Squeeze the handle of the Y-rail release mechanism, lift

it out of its locked position, and slide it downward as far as it will

go.

Doing this aligns the Y-rails with the Y-rails of the module beneath it.

1 Front Y-rail

2Rear Y-rail

3 Y-rail (this end up)

4 Squeeze here to release

Caution: Check to make sure that there is no gap between the top

and bottom Y-rails on both the front and back of the

library. If a gap exists, the library cannot mechanically

initialize.
