Quantum Scalar i500 User Manual

Chapter 12 Installing, Removing, and Replacing
Adding Expansion Modules to an Existing Library
Scalar i500 User’s Guide 354
Figure 56 Cover Plate Location
After Adding an Expansion
Module
* Recommended location for adding an expansion module.
3 Open the expansion module’s access door and raise the guide pin by
pulling it up and turning it slightly as if it were a screw. Otherwise,
the guide pin may scratch the front doors of the module on which
you are stacking it.
5U 14U 23U 32U 41U
cover plate
cover plate NEW Expansion
Module*
cover plate Control
Module
Control
Module
cover plate Control
Module
Expansion
Module
Expansion
Module
cover plate Control
Module
Expansion
Module
Expansion
Module
Expansion
Module
Control
Module
NEW Expansion
Module*
NEW Expansion
Module*
NEW Expansion
Module*
Expansion
Module
cover plate cover plate cover plate cover plate cover plate

Quantum Scalar i500 Specifications

General

Form Factor	Rack-mountable
Product Type	Tape Library
Weight	Varies by configuration
Power Consumption	Varies by configuration
Drive Support	LTO-8, LTO-7, LTO-6
Management	Web-based remote management
Drive Type	LTO Ultrium
Supported Media	LTO-5, LTO-6, LTO-7, LTO-8
Operating Temperature	10°C to 35°C
Humidity	20% to 80% (non-condensing)
Interface	SAS
