Chapter 12 Installing, Removing, and Replacing
Adding Expansion Modules to an Existing Library
Scalar i500 User’s Guide 358
a From the front of the library, open the I/E station and access
doors of the expansion module.
b Squeeze the handle of the Y-rail release mechanism, lift it out of
its locked position, and slide it downward as far as it will go.
c From the back of the library, find the rear Y-rail release
mechanism, which is located in the interior of the right side of the
module. Squeeze the handle of the Y-rail release mechanism, lift
it out of its locked position, and slide it downward as far as it will
go.
Doing this aligns the Y-rails with the Y-rails of the module
beneath it.
1 Front Y-rail
2Rear Y-rail
3 Y-rail (this end up)
4 Squeeze here to release
Caution: Check to make sure that there is no gap between the top
and bottom Y-rails on both the front and back of the
library. If a gap exists, the library cannot mechanically
initialize.
