Quantum Scalar i500 User Manual

Chapter 12 Installing, Removing, and Replacing
Preparing to Remove or Replace a Module
Scalar i500 User’s Guide 369
13 Remove all power supplies from each module that you intend to
remove. For details, see Adding, Removing, and Replacing Power
Supplies on page 420.
14 Remove all tape drives from each module that you intend to remove.
If you are going to replace the module, label the drives with their
locations so you can re-install them in the same locations later. For
details, see Adding, Removing, and Replacing Tape Drives
on
page 444.
1 Parking tab in “parked” position

Quantum Scalar i500 Specifications

General

Form Factor	Rack-mountable
Product Type	Tape Library
Weight	Varies by configuration
Power Consumption	Varies by configuration
Drive Support	LTO-8, LTO-7, LTO-6
Management	Web-based remote management
Drive Type	LTO Ultrium
Supported Media	LTO-5, LTO-6, LTO-7, LTO-8
Operating Temperature	10°C to 35°C
Humidity	20% to 80% (non-condensing)
Interface	SAS
