Chapter 12 Installing, Removing, and Replacing
Replacing an Expansion Module
Scalar i500 User’s Guide 395
Warning: All libraries taller than 14U must be installed in a rack
having a main protective earthing (grounding)
terminal, and power must be supplied via an
industrial plug and socket-outlet and/or an appliance
coupler complying with IEC 60309 (or an equivalent
national standard) and having a protective earth
(ground) conductor with a cross sectional area of at
least 1.5 mm
2
(14 AWG).
To ensure proper airflow and access space, Allow 60
cm (24 inches) in the front and back of the library.
Warning: Without tape drives, tape cartridges, or power
supplies, a control module weighs approximately 60
lbs (27.2 kg). An expansion module, without tape
drives, tape cartridges, or power supplies, exceeds 65
lbs (29.5 kg).
To avoid serious injury, at least two people are
required to safely lift the modules.
