Quantum Scalar i500 User Manual

Library Power Consumption and Heat Output
Scalar i500 User’s Guide 536
UDS3 IBM LTO-4 Drive Sled Module (SAS) 0.038 129.7
UDS3 HP LTO-4 Drive Sled Module (Fibre Channel) 0.037 126.2
UDS3 HP LTO-4 Drive Sled Module (SAS) 0.035 119.4
UDS3 IBM LTO-5 Drive Sled Module (Fibre Channel) 0.048 163.8
UDS3 HP LTO-5 Drive Sled Module (Fibre Channel) 0.030 102.4
UDS3 HP LTO-5 Drive Sled Module (SAS) 0.028 95.5
UDS3 IBM LTO-6 Drive Sled Module (Fibre Channel) 0.034 116.0
UDS3 IBM LTO-6 Drive Sled Module (SAS) 0.032 109.2
UDS3 HP LTO-6 Drive Sled Module (Fibre Channel) 0.030 102.4
UDS3 HP LTO-6 Drive Sled Module (SAS) 0.028 95.5
UDS3 HP LTO-7 Drive Sled Module (Fibre Channel) 0.028 95.5
Fibre Channel I/O Blade 0.080 272.8
Ethernet Expansion Blade 0.010 34.1
Control Module:
Minimum (no drives installed; robot not moving) 0.047 160.0
Maximum (2 drives writing; robot moving) 0.166 565.0
Expansion Module:
Minimum (no drives installed; robot not moving) 0.012 41.0
Maximum (4 drives writing; 2 Fibre-Channel I/O blades
installed; robot moving)
0.256 879.0
Library Configuration
Typical Power
Consumption
(kW/Hour)
Typical Heat
Output
(BTU/Hour)

Quantum Scalar i500 Specifications

General

Form Factor	Rack-mountable
Product Type	Tape Library
Weight	Varies by configuration
Power Consumption	Varies by configuration
Drive Support	LTO-8, LTO-7, LTO-6
Management	Web-based remote management
Drive Type	LTO Ultrium
Supported Media	LTO-5, LTO-6, LTO-7, LTO-8
Operating Temperature	10°C to 35°C
Humidity	20% to 80% (non-condensing)
Interface	SAS
