R&S ESR Series User Manual

System Configuration
R&S
®
ESR
524User Manual 1175.7068.02 ─ 12
●
"Hardware Info" on page 524
●
"Versions+Options" on page 524
●
"System Messages" on page 524
●
"Clear All Messages" on page 525
Hardware Info ← System Info
Opens a dialog box that displays hardware information, e.g. on the frontend and moth-
erboard. Every listed component is described by its serial number, order number,
model information, hardware code, and hardware revision.
Remote command:
DIAGnostic<n>:SERVice:HWINfo? on page 925
Versions+Options ← System Info
Opens a dialog box that displays a list of hardware and firmware information, including:
Label Description
Device ID Unique ID of the device
Instrument firmware Installed firmware version
BIOS Installed BIOS version
CPLD CPLD version
MB-FPGA Motherboard FPGA version
Data Sheet version Data sheet version of the basic device
<option> Installed hardware and firmware options
"Open Source Acknowledgment:
Open"
Displays a PDF file containing information on open source code
used by the R&S ESR firmware.
For details on options, refer to Chapter 3.2.1.10, "Checking the Supplied Options",
on page 46.
Remote command:
*IDN? on page 916
*OPT? on page 917
SYSTem:DEVice:ID? on page 924
System Messages ← System Info
Opens the "System Messages" dialog box that displays the generated system mes-
sages in the order of their occurrence. The most recent messages are placed at the
top of the list. Messages that have occurred since the last display of system messages
menu are marked with an asterisk '*'. The following information is available:
No device-specific error code
Message brief description of the message
Component hardware messages: name of the affected module
software messages: name of the affected software
Date/Time date and time of the occurrence of the message
Instrument Setup and Interface Configuration – SETUP Key
