R&S ESR Series User Manual

System Configuration
R&S
®
ESR
523User Manual 1175.7068.02 ─ 12
●
"Select Print Color Set" on page 523
●
"Color (On/Off)" on page 523
●
"Select Object" on page 545
●
"Predefined Colors" on page 545
●
"User Defined Colors" on page 545
●
"Set to Default" on page 545
Remote command:
HCOPy:CMAP<item>:HSL on page 959
Select Print Color Set ← Print Colors ← Display Setup
Opens the "Select Print Color Set" dialog box to select the color settings for printout.
Screen colors (Print) Selects the current screen colors for the printout. The background is
always printed in white and the grid in black.
Screen colors (Hardcopy) Selects the current screen colors without any changes for a hard-
copy. The output format is set via the "Device Setup" on page 544
softkey in the "Print" menu.
Optimized colors Selects an optimized color setting for the printout to improve the visi-
bility of the colors (default setting). Trace 1 is blue, trace 2 black,
trace 3 green, and the markers are turquoise. The background is
always printed in white and the grid in black.
User-Defined colors Enables the softkeys to define colors for the printout.
Remote command:
HCOPy:CMAP<item>:DEFault on page 959
Color (On/Off) ← Print Colors ← Display Setup
Switches from color printout to black-and-white printout and back. All colored areas are
printed in white and all colored lines in black. This improves the contrast. The default
setting is color printout, provided that the selected printer can produce color printouts.
Remote command:
HCOPy:DEVice:COLor on page 961
Display Pwr Save (On/Off) ← Display Setup
Switches the power-save mode for the display (On/Off) and opens an edit dialog box to
enter the time for the power-save function to respond. After this time, the display is
switched off completely, i.e. including backlighting. This mode is recommended when
the instrument is exclusively operated in remote control.
For details on the power-save mode for the display, refer to Chapter 3.2.4.5, "Setting
the Display Power Save Function", on page 53.
Remote command:
DISPlay:PSAVe[:STATe] on page 980
DISPlay:PSAVe:HOLDoff on page 979
System Info
Opens a submenu to display detailed information on module data, device statistics and
system messages.
The submenu contains the following commands:
