R&S ESR Series User Manual

Remote Control
R&S
®
ESR
992User Manual 1175.7068.02 ─ 12
Manual operation: See "REV String User" on page 517
SYSTem:RSW <State>
Controls a repeated sweep of the E1 and MKPK HI/HL HP model commands (for
details on the commands refer to Chapter 11.18, "GPIB Commands of HP Models
856xE, 8566A/B, 8568A/B and 8594E", on page 1039). If the repeated sweep is OFF,
the marker is set without sweeping before.
This command is only available if a HP language is selected using SYSTem:LANGuage
.
Parameters:
<State> ON | OFF
*RST: OFF
Example:
SYSTem:RSW ON
Usage: SCPI confirmed
Manual operation: See "Sweep Repeat (On/Off)" on page 516
SYSTem:LANGuage <Language>
This command defines the system language. Default is SCPI which defines the stan-
dard remote control behavior of the instrument. The other parameters are to simulate
the corresponding HP analyzer. The parameter "PSA89600" sets the device in a state
in which it can be used for IQ capturing from the 89600 vector signal analyzer soft-
ware.
Parameters:
<Language> "SCPI" | "8560E" | "8561E" | "8562E" | "8563E" | "8564E" |
"8565E" | "8566A" | "8566B" | "8568A" | "8568A_DC" | "8568B" |
"8568B_DC" | "8591E" | "8594E" | "71100C" | "71200C" |
"71209A" | "PSA89600" | "PSA" | "ESA"
*RST: SCPI
Example:
SYST:LANG '8560E'
Sets the system language to 8560E to simulate the HP analyzer.
Manual operation: See "GPIB Language" on page 515
Note: If you use "PSA89600", you must switch to an HP language first before return-
ing to SCPI (in remote operation only). For the identical language "PSA", this inter-
mediate step is not necessary.
SYSTem:HPCoupling <CouplingType>
Controls the default coupling ratios in the HP emulation mode for:
●
span and resolution bandwidth (Span/RBW) and
●
resolution bandwidth and video bandwidth (RBW/VBW)
