Rockwell Automation Publication 2198-UM002L-EN-P - October 2021 371
Appendix B Upgrade the Drive Firmware
After the upgrade information is
sent to the drive, the drive resets
and performs diagnostic
checking.
14. Wait for the Progress dialog box to
time out.
It is normal for this process to take
several minutes.
15. Verify that the Update Status dialog box appears and indicates success or
failure as described below.
16. Click OK.
IMPORTANT
Do not cycle power to the drive during this process. A power cycle
results in an unsuccessful firmware upgrade and an inoperable
module.
Upgrading Status If
Success Update complete appears in a green Status dialog box, then go to step 16.
Failure
Update failure appears in a red Status dialog box, then refer to the
ControlFLASH Firmware Upgrade Kit User Manual, publication 1756-UM105
for troubleshooting information.
IMPORTANT
You must return to the drive Module Properties>Connection category
to clear the Inhibit Module checkbox before resuming normal
operation.
