DMG 3200/3100/3000 – User Manual
Page 117 (306)
value is 7500 (unless manually assigned) while the maximum PID value is
8191. If several ECMs are used in an MPTS output, the ECM values will be
incremented: 7501, 7502, … etc.
Listening Port
For EMM transfer over UDP configured, then the UDP port must be defined
when configuring the actual EMM
State
OPEN or CLOSE
RX Bytes
The total number of bytes received by the generator
At this point, the EMM/PD stream is defined and the CA system is able to push
content to the SCS module. However, the EMM/PD is still not associated to any
output. Refer to the Output Configuration chapter for details on how to associate
EMMs to outputs.
To change an, EMM/PD configuration click on the existing EMM/PD entry and enter the new
configuration.
Figure 6.27 - Edit an existing EMM/PD
