Sencore DMG 3200 - Dual IP Output

DMG 3200/3100/3000 – User Manual
Page 150 (306)
7.4.3 Dual IP Output
The Dual IP output module allows two individual output interfaces to be connected to network
sources, but for the system, this is exactly the same as two IP output cards. The output streams
can be either SPTS (VBR or CBR mode) or MPTS.
All function and status normally associated with IP output modules are present but the total
Output Bitrate for both IP ports cannot exceed 850 Mbps or 250 services, ie the limit is shared
between the two ports.
Figure 7.38–Dual IP Output Configuration
