DMG 3200/3100/3000 – User Manual
Page 287 (306)
Figure 10.36 - Setting up EMMG redundancy
However, it is not compulsory to add this IP Filter. Using the value 0.0.0.0 ensures that the
EMMG connection will not validate the Source IP address (of the EMMG). In addition, multiple
sources may connect to the same listening port, but not concurrently.
If a Main and a Backup EMMG are present in the system, the first EMMG to connect will be the
active one. A connection from the second unit will be rejected as long as an EMMG is currently
active.
It is not possible to manually switch the EMMGs as this connection controlled
by the EMMG itself.
11 Control And Monitoring
11.1 System Status
The system status of the unit can be monitored easily from the web GUI’s Status node.
Information regarding services currently configured, active alarms, alarm history, etc. can be
found here.
11.1.1 Service View
Expand the Status node in the Navigation Pane and click on the Service View node. The
Service View will be displayed as shown below.
