DMG 3200/3100/3000 – User Manual
Page 92 (306)
Additional status parameters for DVB-T2 demodulation:
Pre LTPC BER
Bit error rate before LDPC error correction
Pre BCH BER
Bit error rate after LDPC / before BCH error correction, should <10
-
7.
Number of PLPs
Specify the count of PLPs
PLP Id
Specify the PLP Id
Rotated Constellation
Rotated Constellation of the currently tuned channel.
FEC
Forward Error Correction.
6 Conditional Access Configuration
The unit supports descrambling and scrambling given that the required modules have been
installed. Descrambling and scrambling are processing elements; hence they are not listed in
the Input or Output nodes. These functions are found as part of the output service
configuration.
Figure 6.1 - Conditional Access Node
The Conditional Access node displays existing configuration for CAMs, SCSs, Scramblers
and Descramblers.
The following parameters are available:
CAM:
Services
Number of services being descrambled by the CAM
