DMG 3200/3100/3000 – User Manual
Page 177 (306)
regardless of the network.
SDT
Check this box to synchronize SDT
NIT
Check this box to synchronize NIT
Status
Provides feedback on result of last synchronization attempt; if no
attempt has been made, Not Synced is displayed.
Date
Time and date of last synchronization attempt; if no attempt has
been made, this field is empty.
Action
Retrieve Now initiates a download of selected sections from the
external unit. If the operation succeeds, the Status displays OK
and the output PSI will automatically be regenerated using the
received external sections.
Remove removes the table entry and the output PSI is
automatically regenerated so that all traces of external transport
streams from the external unit are removed.
7.6.7 Inserting Generic Descriptors
The Generic Descriptor insertion functionality (accessible from the PSI dialog by clicking on the
respective tab) allows insertion of arbitrary PSI descriptors into selected DVB output table
descriptor loops. This feature is useful when an important descriptor is private or currently
unsupported.
Figure 7.67 - Generic Descriptor Tab
Each entry displayed in the table corresponds to a single generic descriptor placement.
Clicking on allows new descriptor entries to be inserted, initiating a sequence of context
dependent configuration options via drop down boxes described in the following tables:
Table
Selected desired output table
Playout Placement
A series of table dependent drop down boxes to select the desired
descriptor loop locations:
Net ID/TS ID – DVB Network and Transport Stream ID of
