DMG 3200/3100/3000 – User Manual
Page 134 (306)
Figure 7.20 - PSI Tab for a service encapsulated within an MPTS
If the Global PMT (accessible via Outputs
PSI) mode is set to Stop, PMTs
for services within the MPTS will not be played, regardless of their mode.
7.3.6 EPG
The EPG tab enables transmission of EIT schedule information on a particular output stream, if
an EPG module is installed. Further information on these parameters is available in Section 9.3
.
Figure 7.21 - EPG Tab for IP Modules
The EPG tab is identical for both MPTS and SPTS.
7.3.7 Service
To modify the settings for individual services, double click on the service and the Service
Properties dialog will be displayed. The Service tab is identical for both MPTS and SPTS.
