DMG 3200/3100/3000 – User Manual
Page 214 (306)
Video Resolution
Encoded video resolution; Depends on the configured video format
and horizontal rescaling. Horizontal Resolution x Vertical Resolution.
Edit
Edit option to change the transcoder parameters.
Click edit and the configuration pages will be displayed. The configuration parameters are
organized into different sections selectable from the tab menu on top. Source Parameters
8.5.1 Source Parameters
For viewing transcoder source parameters, please select the Source tab.
Figure 8.29 -
Universal Broadcast Transcoder source parameters
The following parameters are available:
Service Name
The name of the incoming service that are transcoded. This field is
empty if no service is selected.
Service Type
Service type received for this service. This is meta data in DVB SI and
may not correspond to the actual video codec and format received.
The service type corresponds to the Service type settings in the
Service tab of each output board and can be changed if required
Component
Details on received components for the selected service:
• PID -> PID number received
• Type -> Type of component for selected PID
• Rate -> Bit-rate for selected PID
• Info -> additional information such as language code
