DMG 3200/3100/3000 – User Manual
Page 199 (306)
encoding – normal operation
stopped – error unless reconfiguring
off – encoder is disabled
Edit
Edit option to change the transcoder parameters.
The detailed status found by clicking on the Input Port (ie A. B. etc), includes information
about the input video parameters and output video parameters.
Click edit and the transcoder configuration pages will be displayed. The configuration
parameters are organized into different sections selectable from the tab menu on top.
Common sections for encoder module and transcoder module are described in section 8.3.34.
The following sections describe only information specific to the transcoder.
8.3.1 Source Parameters
For viewing transcoder source parameters, please select the Source tab.
Figure 8.16 – Transcoder Source View
The following parameters are available:
Service Name
The name of the incoming service that are transcoded. This field is
empty if no service is selected.
Service Type
Service type received for this service. This is meta data in DVB SI and
may not correspond to the actual video codec and format received.
The service type corresponds to the Service type settings in the
