DMG 3200/3100/3000 – User Manual
Page 17 (306)
2.1.4 Installation
2.1.4.1 Power supply rating
The 4RU chassis is supplied with either a 100-240V AC 50/60 Hz power or -48V DC power.
The 100-240V AC 50/60 Hz power supply is rated for maximum 300W, 400W or 800W
1
. The -
48V DC power is rated for maximum 400W. Figures 2.6. 2.7, 2.8, 2.9, 2.10, 2.11 and 2.12
below shows the power supply inlets.
The 1RU chassis is supplied with a 100-240V AC 50/60 Hz power rated for maximum 200W
for product models DMG 3100.
The 1Ru chassis, product model DMG 3200, is supplied with single or dual 100-240V AC, 47-
63Hz , 400W power, or with single or dual -48V DC, 500W power.
2.1.4.2 4RU chassis with 300 and 400W AC Power
The chassis can be hold two power supplier for redundancy and has independent power inlets
for the two supplies.
Figure 2.6 - Power Input for 4RU chassis with 300 and 400 Watt AC power
1
Contact Sencore for more information.
