Sencore DMG 3200 - Edit Options on Existing Manual PSI

DMG 3200/3100/3000 – User Manual
Page 54 (306)
• aac_adts
• e-ac3-e
Language
The language signaled on the input. If this is not a filtering criteria then use
wildcard “*”
Override
The new language descriptor to be used for the incoming component.
Note
• If several PIDs are matching the input filtering criteria’s, then the signaling for all
these components will be updated.
• If the input signaling is dual mono, and no Language (source) is specified, then the
right channel descriptor will be replaced.
5.3.5 Edit options on existing manual PSI
Under the Manual-PSI node all current manual PSI rules will be listed. Not all rules can be
changed once they are defined. These are indicated with a blue circle with the “?” mark. To
change these components they need to be removed and re-added. The rules indicated with a
pencil can be changed without remove / add operation.
Figure 5.15 – Editing existing Manual PSI
