DMG 3200/3100/3000 – User Manual
Page 101 (306)
6.2.1 Verimatrix Configuration
The following parameters are available:
Slot
Slot in which the descrambler module is installed
Services
Number of services currently active
Algorithm
Descrambling is performed in FPGA. Depending on the FPGA installed,
different algorithms will be available. Select an algorithm after installing a
descrambler.
Company
Name
A unique key that will be exchanged with the CA system (provided by your
CA vendor)
Server IP
IP address of the CA vendor’s server
Server Port
CA vendor port to be used
Bitrate [Mbps]
Total bitrate passing through the descrambler
Edit This is a Verimatrix specific parameter.
It is possible to configure the verimatrix.ini file via the edit link. The dialog
shown in Figure 6.9 will be displayed.
Figure 6.9 - Configuring Verimatrix Parameters
