DMG 3200/3100/3000 – User Manual
Page 301 (306)
12.5 Restoring the Default IP Address
It is possible to restore to the factory-configured IP address on the Switch+MMI module. This
can be useful if the software-configured IP address is lost. The restore is done by setting dip
switch 2 to ON on the Switch+MMI card. When the setting has been applied, the MMI will be
configured according to the tables below regardless of what is stored in memory.
The default IP settings are:
IP Address
192.168.1.100
Subnet Mask
255.255.255.0
Default Gateway
192.168.1.1
After setting the DIP switch the MMI card has to be rebooted. The factory default IP settings will
be active as long as the setting is present. While the DIP switch on, all IP parameters in
memory can be changed and saved via the web interface. Once the DIP switch is changed
back to OFF and the card is rebooted, the IP settings in memory will be activated.
Figure 12.3 - Hardware IP reset DIP switch
