7.6 PSI/PSIP Configuration
The unit offers PSI/SI as well as initial PSIP regeneration support – with a table profile mode of
either DVB or ATSC. This setting determines which tables are available for regeneration and
subsequently, which tables will be listed in the GUI dialogs.
Below is an outline of the supported tables together with which profile(s) they are available in.
DVB or ATSC tables that are not listed below are currently not supported.
Table
Available
in
Profile(s)
Default
Playout
Interval
(ms)
Supported function
PAT
DVB
ATSC
200 Generated by the unit
CAT
DVB 500 When CAT is in play mode then the CAT is generated
by the unit.
When the EMM is mapped from the input, using the
include EMM on the Transport node, then the CAT
Mode should be set to stop as the CAT and EMM is
copied from the input.
PMT
DVB
ATSC
200 Regenerated from input. Service ID and component
PIDs and PMT PID may be remapped. Table is
automatically updated to reflect any PID
filtering/remapping done in the GUI.
BAT
DVB 1000 Generated by User Input from GUI.
NIT-A
DVB 2000 NIT is generated based on the values entered by
user. All transports defined in the same network will be
included in NIT.
NIT Other is not supported
IF NIT is not enabled then PID 16 (0x0010) will not be
transmitted.
The NIT supports the following descriptors:
• Delivery descriptors
• Logical Channel Descriptors
SDT-A
DVB 1000
Regenerated from input, if available, otherwise
generated.
The Service ID, name, provider and type can be
modified.
SDT-O
DVB 5000 Content is identical to corresponding SDT-A.
EIT P/F-A
DVB 1000 Regenerated from input
