DMG 3200/3100/3000 – User Manual
Page 169 (306)
EIT P/F-O
DVB 5000 Regenerated from input. Supported in MPTS mode
only.
TDT
DVB 15000 Generated based on system time
TOT
DVB 15000 Generated based on system time
A single TOT with a single Local Time Offset
Descriptor can be defined globally per unit. The
playout mode of t
he globally defined TOT is still
configurable per Transport Stream.
MGT
ATSC 100
PSIP Master Guide Table. Generated based on
currently active PSIP tables.
TVCT
ATSC 200 Terrestrial Virtual Channel Table, Regenerated based
on input, if available, otherwise generated.
Short Channel Name and program_number can be
modified (use DVB Service Name and Service ID
editing - see section 7.3.7 for details).
Input Service Location Descriptor is regenerated
based on desired PID mapping, but not generated if
there is no input.
CVCT
ATSC 200 Same as TVCT. Cable specific parameters are copied
from input or assigned default values (path_select =
path1 and OOB = false)
The PSI is designed to offer a global default configuration as well as configurations of individual
tables for each transport stream. The global configuration can be used as a default, but if
needed, the individual tables on each MPTS/SPTS output can be configured independently.
PAT and PMT tables should always be included on an outgoing transport
stream.
Event Information related tables like EIT P/F-A and EIT schedule are configured
in the EPG section (requires EPG module for EIT schedule).
