8.4 Common Encoder/Transcoder Configuration
8.4.1 Video Parameters
The following parameters are available for video configuration:
Figure 8.21– Video encoder configuration-Aspect Ratio
Encoder Type
Selects compression standard to use. Available options are: H.264
(MPEG-4 part 10) or MPEG-2 video codec.
Aspect Ratio
Selects the aspect ratio to be signalled in the output video:
• 16x9
• 4x3
• 1x1
• WSS (Encoder only)
• WSS (line 18) ( Encoder only)
• Video Index 11/324 (Encoder only)
• Video Index 8/321 (Encoder only)
• Transparent (Transcoder only)
AFD
AFD codes has below options:
• Pass through: AFD codes transparent from SDI input to
Video output stream.
• Off: AFD codes are not passed from SDI input to video
output stream.
Profile
Selects the encoder profile to be used. The profile determines the
range of tools from the codec “toolkit” that the encoder is allowed to
utilize when encoding. The level is set automatically depending on
the current configuration.
