DMG 3200/3100/3000 – User Manual
Page 227 (306)
When configuring the expected frame rate, the detailed information about the
input service in the Universal Transcoder- Multiscreen status and configuration
page could be of help.
8.6.1 Video Parameters
This page contains the parameters governing the common timing of the profiles. If the path to
configure is GOP aligned to another path, then the parameters in this page are copied from the
reference path.
All Data PIDs (TTX, DVB sub, DPI/LPI) from input service will be passed through to all
transcoded output profiles by default. User can stop these PIDs in the component mapping
filter on the transcoded output stream.
Figure 8.40 –
Universal Transcoder- Multiscreen video parameters
Figure 8.41 – Universal Transcoder- Multiscreen subtitling parameters
