DMG 3200/3100/3000 – User Manual
Page 51 (306)
The PMT PID may be defined with any value from 32 to 8190, but ensure that
it is unique in an MPTS configuration scenario. Also, if this input is part of an
outgoing digital stream, the PMT PID here is the PID value that will be
assigned for the outgoing PMT.
When an input service is defined the following tables are generated:
• PAT
• PMT
All other table analysis is cancelled for this input port. The result is listed in the GUI (see Figure
5.10).
Figure 5.10 - Table Analysis when an Input Service is defined
This entry may be edited or deleted later using the corresponding icons on the left.
5.3.1 MPTS Support
If multiple services are defined for one input, they effectively represent a MPTS.
To check that the manually defined input has entered the system correctly, select the Inputs
node and ensure that the service information is present. In the example below (Figure 5.11)
Service number 30 (under the Services panel) is represented with PSI even though the input
has not yet been added to the system.
