DMG 3200/3100/3000 – User Manual
Page 135 (306)
Figure 7.22- Service Tab for IP SPTS
The following parameters are available for configuration:
Name
By default, these four values are extracted from the incoming streams
automatically. They can be overwritten manually by deselecting Keep Original
and entering a new value.
Service Id
PMT PID
Provider
Service type
Priority
An internal system parameter which may be used for different purposes.
Currently it is an attribute used by the Output Redundancy system only.
Monitor Port
Provides a way to monitor a service if the system is configured with a decoder
module. If enabled, a copy of the service is sent to the selected decoder. If the
service is descrambled, the service is copied after descrambling.
Refer to the Input Redundancy (Section 10.1) for more information on the Backup source and
Switching mode parameters.
Descrambler
Select which descrambler to be used for removing the incoming
encryption. If multiple services are being descrambled, they must
originate from the same input port (same MPTS).
Alt. CAM mode
Configuration of these values is moved to the main conditional access
page in the Navigation Pane.
