DMG 3200/3100/3000 – User Manual
Page 258 (306)
Figure 10.6 - Port Configuration seamless input Redundancy
Enable Port
This option is added to enable the operator to block one path -> hence
forcing the input to be taken from the other port
Source IP
The source IP should be defined.
Filter input
synchronization
alarm
If source is not cloned output then if it is checked then will raised alarm for
it.
This option can be used to use Input Redundancy for multicasts from
different sources. When in this module, the resulting stream will not be
seamless.
The switching time when ‘No bitrate’ on the main port is 100ms.
