DMG 3200/3100/3000 – User Manual
Page 278 (306)
The SDI inputs to the main cards are connected directly, while the input to the spare cards is
connected via the SDI switch.
To add a new switch press the “+” sign and enter the relevant parameters.
Figure 10.29 – External switch configuration.
Figure 10.30 – External switch properties.
Name
Specify the Name of the Switch.
IP address
Insert the IP address of the SDI switch
Input ports
Specify the number of Input ports.
Output ports
Specify the number of Outputs ports.
