DMG 3200/3100/3000 – User Manual
Page 290 (306)
Figure 11.3 Output View
Information in the Output View can be sorted by clicking on the column headers. It is possible
to search within this page by using the field with the magnifying glass in the top right corner. The
Output View shows all configured outputs by default and the following information is available:
Output
Information about the output port. This will be specific to the type of output,
ie IP will include multicast address, QAM will include frequency.
Services
Lists the number of services in the given output port
Effective Bit Rate
Shows the current effective bitrate of the output port
Total Bit Rate
Shows the current total bitrate configured for the output port
EPG
Displays if there is currently EPG information (EPG Schedule) configured
on the output port
It is possible to select and deselect information in this view by clicking on the ‘…’ in the top right
hand corner of the title bar. This will bring up the following dialog:
