Input
Port on the DVB-S/S2 input module
Rate [Mbps]
Incoming data rate
CC Err
Continuity Counter Error – indicates that one or more packets are lost
Mode
PSI/SI Analysis mode.
SATF [GHz]
Satellite Frequency
SRate
Symbol Rate – specify the symbol rate of the incoming DVB-S/S2
signal. The demodulator’s range is 950 – 2150 MHz.
Modulation
Select one of the following modes:
Auto (only for HW Rev. 2.0)
DVB-S
DVB-S/S2_QPSK
DVB-S/S2_8PSK
DVB-S/S2_16APSK (only for HW Rev. 2.0)
DVB-S/S2_32APSK (only for HW Rev. 2.0)
ICode
Inner Code – specify the FEC overhead fraction
LNBV
LNB Voltage – select the output voltage from the dropdown box
22kHz
Switch the 22kHz output signal on or off
Enable
Enable the corresponding input port
The above list of parameters can be configured by clicking on the edit link to the right of each
input. The pop up dialog below will be displayed:
