DMG 3200/3100/3000 – User Manual
Page 73 (306)
VLAN
Displays available VLANs; the default value is off.
Select a suitable VLAN if required.
The IP input window shows all configurable settings as well as the current bitrate and service
information. The following parameters are available:
Input
Port on the IP input module – assigned automatically when joining a unicast
or multicast.
For Switch with IP modules, the Port A will use input numbers 0 to 249, Port
B will use input 1000 to 1249.
IP
IP address of the multicast or unicast
Port
Port of the multicast or unicast
Rate [Mbps]
Incoming data rate
CC Err
Continuity Counter Error – indicates that one or more packets are lost
RTP Err
Real-time Protocol Error – represents the number of discontinuities on the
RTP counter if RTP is enabled on source. If RTP is not enabled on the
source, N/A is displayed.
Mode
The mode of the input stream.
De-Jitter
Checking this check box activates the de-jitter algorithm on the input port.
Enabling this algorithm is recommended in order to achieve the best results.
However, in some cases, if the input quality is very poor or missing PCR PID,
a better result may be achieved by disabling this feature. Note that the output
from the streamer will be very poor as well.
For IP input modules, clicking on the IP address under the IP column allows for the IP, Port,
Mode, Dejitter, Name, IGMPv3/SSM, and VLAN parameters to be edited.
