DMG 3200/3100/3000 – User Manual
Page 95 (306)
• A list of available CAM modules with its corresponding name,
• The chassis slot where the Descrambler module is installed, and
• The CAM slot (each Descrambler module has two CAM slots labeled A and B).
Figure 6.3 - CAM Configuration Page
If there is no CAM module in the Descrambler module, CAM Name will be displayed as not
available.
The Alt CAM Mode, CAM Interface, EMM Source, Auto Reset, Reset and Max TS Rate are
the configuration fields available in this page (Figure above).
Slot
Slot in which the Descrambler is installed
CAM Slot
Slot in which the CAM module is installed – either slot A or B
CAM Name
Name of the CAM module
Alt CAM Mode
Activate sending of the entire input stream to the CAM without PID
filtering - explained in detail in Section 6.1.4.
CAM Interface
Displays the menu defined by the CAM manufacturer – explained in
detail in Section 6.1.5.
EMM Source Displays the source of the EMM, the default value is auto.
