Siemens HiPath 1120 Programming Manual

Step by step
ADSL expansion boards
166
ADSL Module
This is a previous version used initially on HiPath 1100
V6.0 equipped with ADSL modem functions and LAN
interface on the same board.
The parameters required for this to work correctly must
be set using the administration software ”HiPath 1100
ADSL Manager” Æ page 188.
SLIMC, SADSLIM, LIMC and ADSLIM
modules
This version includes the set comprising a LIM module
(ADSL expansion board) and the ADSL modem, which
can be optionally mounted on the board.
• HiPath 1120: SLIMC module (LAN) and SADSLIM
module (LAN + ADSL modem)
• HiPath 1150/1190: LIMC module (LAN) and AD-
SLIM module (LAN + ADSL modem)
These modules already have the CommServer applica-
tion installed and do not need to be connected directly
to a PC to administer the PABX, only to the LAN.
To set the required parameters of the modules, use the
”Configuring the SpeedStream 4100 modem”
Æ page 190 and the administration tool ”Siemens Ad-
min Console” Æ page 188 (See Service Manual - Ap-
plications of the HiPath 1100)
The ADSL modem used is the Siemens Speed-
Stream 4100. You can consult the configuration
instructions in the manual which you will find in
the Setup and Installation CD.
