Setup and Installation

225

ADSL expansion boards

These can only be installed in slots 3 or 4 in the HiPath 1150 (Æ page 219)

and in slot 2 in the HiPath 1190.

module

The S

module can only be installed in Slot 3 on the HiPath 1150

(Æ page 219) and Slots 1 and/or 11 on the HiPath 1190.
