Simplex 4100ES Installation Guide

E-1
Appendix E
References to 4100ES Module Installation Instructions
Overview
Table E-1. References to 4100ES module installation instructions
PID Description Installation
Instructions
4100-0156 8V DC CONVERTER 574-123
4100-0620 TRANSPONDER IF MODULE 574-848
4100-0621 ANALOG AUDIO RISER MODULE 574-848
4100-0622 DIGITAL AUDIO RISER MODULE 574-848
4100-0623 NETWORK AUDIO I/F MODULE 574-848
4100-0625 LOCAL MODE TPR IF 574-848
4100-0632 UTILITY BLOC, 16 TERMINALS 579-248
4100-0633 TRANSPONDER TAMPER SWITCH 579-195
4100-0634 POWER DIST MODULE 120V 574-848
4100-0635 POWER DIST MODULE 220V 574-848
4100-1210 ANALOG AUDIO CONTROLLER 579-159
4100-1240 AUX AUDIO INPUT MODULE 579-160
4100-1241 MESSAGE EXPANSION, 8 MINUTES 579-172
4100-1242 MESSAGE EXPANSION, 32 MINUTES 579-172
4100-1245 FLEX 50 NAC EXPANSION, 3 CLS B 579-175
4100-1246 FLEX 50 CLASS A ADAPTER 579-175
4100-1248 100W NAC EXPANSION, 6 CLASS B 579-175
4100-1249 100W CLASS A ADAPTER 579-175
4100-1252 AUDIO IF MODULE, SGL CHANNEL 579-168
4100-1253 AUDIO IF MODULE MULTI-CHANNEL 579-168
4100-1254 AUDIO IF 2 CHANNEL 579-168
4100-1255 AUDIO IF 3-8 CHANNEL 579-168
4100-1259 CONSTANT SUPV NAC 25V RMS A/B 579-515
4100-1259 CONSTANT SUPV NAC 25V RMS A/B -
Non-Alarm Audio Mode
579-515
4100-1260 CONSTANT SUPV NAC 70V RMS A/B 579-515
4100-1260 CONSTANT SUPV NAC 70V RMS A/B -
Non-Alarm Audio Mode
579-515
4100-1265 FAIL SAFE MICROPHONE MASTER 579-571
4100-1266 EXPANSION NAC CARD FOR EXP SIG 579-175
4100-1267 EXP SIG CARD CLASS A 579-175
4100-1268 EXP SIGCARD CONSTANT SUPV 579-515
4100-1269 FAIL SAFE MICROPHONE SLAVE 579-571
4100-1270 MASTER TELEPHONE, 3 NACS 579-226
4100-1271 REMOTE MASTER PHONE 579-226
4100-1272 EXPANSION PHONE CONTROLLER 579-226
4100-1273 PHONE CLASS A NAC ADAPTER 579-226
4100-1274 MICROPHONE MUX MODULE 579-879
4100-1276 8 RED PLUGGABLE LED MODULE 574-843
4100-1277 16 RED/YEL PLUGGABLE LED MOD 574-843
4100-1278 16 SW/16 RED/YEL PLUG LED 574-843
4100-1279 2” BLANK DISPLAY MODULE 574-843
4100-1280 8 SWITCH, 8 RED LED MODULE 574-843

Simplex 4100ES Specifications

General

Type	Fire Alarm Control Panel
Display	LCD
Battery Backup	Yes
Model	4100ES
Manufacturer	Simplex
Communication Protocol	Optional Ethernet
Signaling Line Circuits (SLCs)	Up to 10
Notification Appliance Circuits (NACs)	Up to 10
Agency Listings	UL, FM, CSFM, MEA
Max Relay Circuits	20
Communication Ports	Ethernet
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity	Up to 93% RH, non-condensing
