ECDIS-E User Guide Charts
65934012 4-9
The following functions are NOT available when a raster chart is displayed:
changing Presentation Mode - North Up will be the only available
presentation mode when raster charts are selected. If the raster
chart is not north oriented then Chart Up will be the only available
presentation mode.
Implementing any changes to shallow/deep shading values, see
Chart Depths/Heights.
WARNING!
ALTHOUGH SHALLOW/DEEP SHADING VALUES (AS DEFINED IN
CHART DEPTHS/HEIGHTS) MAY BE CHANGED, THESE VALUES
ARE HIGHLIGHTED ON VECTOR CHARTS ONLY. RASTER CHART
CONTOUR AREAS CANNOT BE ADJUSTED IN THIS WAY. SAFETY
CHECKING DOES NOT OCCUR WHEN USING RASTER CHARTS.
Notes on the displayed raster chart may be accessed and viewed via the
Notes tab in the Legend sub-menu.
